AMI Codes-II O3
Program List and Explanations

4 Operation

4.1 Sensors
4.1.1
4.1.1.1
4.1.1.2
4.1.2
4.1.3
4.1.4
4.2 Relay Contacts
4.3 Logger
4.3.1
Interval 1 s
Time 25 min
4.3.2
72
Verification kits:
Verikit low: Set the absorbance value of the verification filter "low" ac-
cording to the calibration certificate.
Range: 0.0000–0.1000
Verikit high: Set the absorbance value of the verification filter "high"
according to the calibration certificate.
Range: 0.1500–0.2000
Filter Time Constant: Used to damp noisy signals. The higher the
filter time constant, the slower the system reacts to changes of the
measured value.
Range: 5–300 sec
Hold after Cal: Delay permitting the instrument to stabilize again after
calibration. During calibration- plus hold-time, the signal outputs are
frozen (held on last valid value), alarm values, limits are not active.
Range: 0–6'000 sec
Meas. Interval: Measurement interval for disinfectants.
Range: 5 to 10 min
See 5.3 Relay Contacts, p. 76
The instrument is equipped with an internal logger. The data can be
copied to a PC with a USB stick if option USB interface is installed.
The logger can save approx. 1500 data records. The records consist
of: Date, time, alarms, measured value, flow, zero, case
temperature.
Range: 1 second to 1 hour
Log Interval: Select a convenient log interval. Consult the table
below to estimate the max logging time. The logging buffer is
designed as circular buffer. If the buffer is full, the oldest data record
is erased to make room for the newest one.
If the logger interval is set to event driven, a data record of every
valid measurement is saved. The interval corresponds with the
measuring interval.
5 s 1 min
2 h 25 h
Clear Logger: If confirmed with yes, the complete logger data is
deleted. A new data series is started.
5 min 10 min
5 d 10 d
30 min 1 h Event
Driven
31 d 62 d
