AMI Codes-II O3
Program List and Explanations
As process
values
5.2.1.40
5.2.1.40.10
5.2.1.40.20
5.2.1.40.13
5.2.1.40.23
74
The process value can be represented in 3 ways: linear, bilinear or
logarithmic. See graphs below.
[mA]
20
B
10 12
0 / 4
0.0 0.1 0.2
A linear
B
bilinear
[mA]
20
10 12
0 / 4
2 4 6
1 10 100 1'000
0 1 2
X Measured value (logarithmic)
Scaling: Enter beginning and end point (Range low & high) of the
linear or logarithmic scale. In addition, the midpoint for the bilinear
scale.
Parameter DIS:
Range low: 0.0–500.0 ppb
Range high: 0.0–500.0 ppb
Parameter Sample flow
Range low: 0 –600 B/s
Range high: 0 –600 B/s
A
0.3 0.4 0.5
X Measured value
X
10'000
3 4
X
