AMI Codes-II O3
Program List and Explanations
2.2.1.4
2.2.1.5
2.2.3
2.2.3.1
2.3 Sample
2.3.1
2.4 I/O State
2.4.1/2.4.2
2.5 Interface
70
Cal. History: Shows the diagnostic values of the last calibrations.
Number: Calibration counter.
Date, Time: Date and time of the calibration.
Slope: Slope is a correction factor calculated on the basis of a
process calibration.
Range: 0.8–1.2
Ver. History: Shows the verification values of the last verifications:
Number: Verification counter.
Date, Time: Date and time of the verification.
Absorbance: Measured absorbance of the reference kit.
Reference value: True value of the reference kit according to label.
Deviation: Deviation between the measured value and the reference
value in %.
Miscellaneous:
Case Temp: Shows the current temperature in [°C] inside the
transmitter.
Sample ID: Shows the identification assigned to a sample. This
identification is defined by the user to identify the location of the
sample.
Sample Flow: Shows the actual sample flow in B/s (bubbles per
second)]. The Sample flow must be above 5 B/s.
Shows current status of all in- and outputs.
Alarm Relay:
Relay 1 and 2:
Input:
Signal Output 1 and 2:
Signal Output 3:
Only available if optional interface is installed.
Review programmed communication settings.
Active or inactive
Active or inactive
Open or closed
Actual current in mA
Actual current in mA (if option is installed)
