AMI Codes-II O3
Program List and Explanations
5.3.1.1
5.3.1.1.1
5.3.1.1.25
5.3.1.1.35
5.3.1.1.45
5.3.1.3
5.3.1.3.1
5.3.1.3.x
5.3.1.3.x
5.3.1.5
5.3.1.6
5.3.2 and 5.3.3
A-96.250.881 / 070622
Alarm DIS.
Alarm High: If the measured value rises above the alarm high value,
the alarm relay is activated and E001 is displayed in the message
list. Range: 0.0–500.0 ppb
Alarm Low: If the measured value falls below the alarm low value,
the alarm relay is activated and E002 is displayed in the message
list.
Range: 0.0–500.0 ppb
Hysteresis: Within the hyst. range, the relay does not switch. This
prevents damage of relays contacts when the measured value
fluctuates around the alarm value.
Range. 0.0–500.0 ppb
Delay: Duration, the activation of the alarm relay is retarded after the
measuring value has risen above/fallen below the programmed
alarm.
Range: 0.00–28'800 sec
Sample Flow: Define at which sample flow a flow alarm should be
issued.
Flow Alarm: Program if the alarm relay should be activated if there is
a flow alarm. Choose between yes or no. The flow alarm will always
be indicated in the display, pending error list, saved in the message
list and the logger.
Available values: Yes or no
Note: Sufficient flow is essential for a correct measurement.
We recommend to program yes.
Alarm High: If the measuring values rises above the programmed
value E009 will be issued.
Range: 100 –600 B/s
Alarm Low: If the measuring values falls below the programmed
value E010 will be issued.
Range: 5–80 B/s
Case Temp. high: Set the alarm high value for temperature of
electronics housing. If the value rises above the programmed value
E013 is issued.
Range: 30–75 °C
Case Temp. low: Set the alarm low value for temperature of
electronics housing. If the value falls below the programmed value
E014 is issued.
Range: -10 to +20 °C
Relay 1 and 2: The contacts can be set as normally open or
normally closed with a jumper. See
The function of the relay contacts 1 and 2 is defined by the user.
Relay 1 and 2, p. 28.
