5.1.2.5.4 Setting Cleaning mode
Operation 1
Operation 2
Operation 3
Operation 4
5.1.2.5.5 Cleaning the Roller
Operation 1
(The Roller is contaminated intentionally for the explanation.)
Ensure your Autoloader is in maintenance mode.
Display (line 1): READY
Display (line 2): F/W Rev.?
Press the arrow key and select "CLEAN ROL?" command.
Display (line 1): READY
Display (line 2): CLEAN ROL?
Press the ENTER key and define the command.
Display (line 1): CLEAN ROLL
Display (line 2): Eject Magz
Remove the magazine carefully.
Display (line 1): CLEAN ROLL
Display (line 2): Step 1 >>
Press the arrow key (→) and define the command.
Then, the Roller of the internal transporter moves the position of the
front side of the transporter as shown in figure 5-2. During moving the
Roller, LCD displays the next messages.
Display (line 1): CLEAN ROLL
Display (line 2): Caution
CAUTION
Do not insert your hands during displaying Caution message
as fingers may be pinched in the Roller.
Figure 5-2
- 46 -
