Operation 8
Wipe off remaining water on the Roller by dry swab.
If you have finished cleaning of the upper Roller, press the arrow key
Operation 9
( → ) and define the command. Then the Roller moves further
backwards a little as shown in figure 5-10.
Display (line 1): CLEAN ROLL
Display (line 2): Step 3 >>
CAUTION
Tip
If you press the arrow key (←) in this position of the Roller, the Roller moves
to previous position as shown in figure 5-9.
Operation 10
Then clean the remaining surface of Roller as shown in figure 5-11.
(Figure 5-12 shows the upper Roller after cleaning.)
Figure 5-11
Figure 5-10
Do not insert your hands during displaying Caution message
as fingers may be pinched in the Roller.
- 49 -
Figure 5-12
