3.4 Removal and Insertion of the Cartridges

The method by which cartridges are removed and inserted is described here.

3.4.1 Removal from and Insertion to the Magazine

1. Hold the magazine body steady and press the center portion of the cartridge. A "click" sound
is heard and the lock is released.
2. Remove the cartridge.
Tip
When removing or inserting cartridges, keep your finger against the cartridge
when pressing on the center portion so that the cartridge does not fall out.
Figure 3-6 Removal and Insertion of Cartridges (7-Slots)
- 19 -
