3.5 Operation of the Panel Keys

3.5.1 Organization of the Front Panel Switches

The arrangement of switches as viewed from in front of the front panel is as illustrated below.

3.5.2 Functions of the Switches

The functions of the various switches are described below.
key(arrow key)
key(arrow key)
ENTER key
ESCAPE key

3.5.3 Slot Logical Numbers

In the Autoloader, logical numbers such as the following are assigned to the slots that house the
cartridges upon execution of the operation command.
Rear of device
ESCAPE
Figure 3-7 Front Panel Switches
: Moves forward through the menu.
: Moves backward through the menu.
: Defines and executes the displayed menu or operation
command.
: Cancels the execution of the selected command, or returns to
the previous screen of the selected menu.
(Top of device)
Drive
Figure 3-8 Slot Logical Numbers
- 21 -
ENTER
10 7
9 6
8 5
4
3
2
1
Front of device
