Tandberg Data Autoloader Tandberg LTO2 Installation And User Manual page 64

If you have finished cleaning of the upper Roller, press the arrow key
Operation 6
(→) and define the command. Then the Roller moves backwards a little
as shown in figure 5-7.
Display (line 1): CLEAN ROLL
Display (line 2): Step 2 >>
CAUTION
Tip
If you press the arrow key (←) in this position of the Roller, the Roller moves
to previous position as shown in figure 5-6.
Operation 7
Then clean about three quarters of the Roller's surface as shown in
figure 5-8. (Figure 5-9 shows it after cleaning.)
Figure 5-8
Figure 5-7
Do not insert your hands during displaying Caution message
as fingers may be pinched in the Roller.
- 48 -
Figure 5-9
