3.4.2 Removal from and Insertion to the Fixed Slots

Operation 1
Operation 2
Operation 3
Operation 4
Operation 5
Operation 6
Operation 7
Operation 8
Operation 9
Tip
•Ejecting by command is valid only when slot numbers 5 to 7 among the
magazine slots are all vacant slots.
•When ejecting by command is executed, all cartridges housed in slot numbers
8 to 10 within the fixed slots are moved to the magazine.
Remove the cartridges that are housed in the fixed slots (i.e., slot 8 to
10). (The cartridges will move to slot 5 to 7 within the magazine at this
time.)
Reload a magazine into the main unit that has vacant slots for slot 5 to
7.
Lock the front door and wait for "READY" to be displayed.
Press the "ENTER" key.
Display: STATUS
Press the "arrow" key and select the EJECT command.
Display: EJECT
Press the "ENTER" key and define the command.
Display: Eject Drv?
Press the "arrow" key and select "Eject Slot?" .
Display: Eject Slot?
Press the "ENTER" key and execute the command.
Display: Complete (when the command ends normally.)
Err. xxxxxx (when an error occurs. xxxxxx is the error code.)
When required, remove the magazine and remove the cartridges of slot
5 to 7 which have been moved.
- 20 -
