Chapter 4 Cartridges

4.1 Cartridges

The Tandberg LTO2 Autoloader uses the following types of LTO cartridges.
･ TD P/N : 432744
･ TD P/N : 432630-1 LTO1 Data Cartridge
･ TD P/N : 432631
To ensure that your Tandberg LTO2 Autoloader conforms to our specifications for reliability, use
only the above cartridges. Below figure shows the overview of a cartridge and its components.
Write-protect switch
LTO2 Data Cartridge
LTO Universal Cleaning Cartridge
Insertion guide
Label area
Figure 4-1 LTO Cartridge
- 31 -
Leader pin
Cartridge door
