1.2 Names and Functions of the Parts

This section describes the names and functions of the Tandberg LTO2 Autoloader parts.

1.2.1 Front Panel of the Tandberg LTO2 Autoloader

① Front door
This door prevents the intrusion of foreign objects. While the power is ON, unlock the door
lock with the door lock key supplied with the main unit.
② Key lock
The front door is locked with the door lock key supplied with the main unit.
Pushing in the key and turning it clockwise 90 degrees will release the lock. The unit should
normally be used with the door locked.
③ Power switch
This switch switches the power of the Autoloader on and off.
A press on the right side ( | ) switches the power ON and a press on the left side (○)
switches the power OFF.
Figure 1-1 Front Panel of the LTO2 Autoloader
Door Locked.
- 2 -
Door Open.
