Peel-Off Mode - Datamax Prodigy Plus Operator's Manual

3. Route the media so that it slides over the rewind adapter as
shown in Figure 1-10.
4. Partially wrap media around the Media Rewinder and install the
clasp over the media.
Figure 1-10

1.7.1 Peel-off Mode

1. If the Peel-off Mode is desired, route the media backing down
past the Rewind Assist Roller, (see Figure 1-10) to the media
rewinder and reverse the serrated tear off plate.
Note: Do not install the rewind adapter when using the
Caution
Prodigy Plus
Routing the Media for Rewinding
Peel-off Mode.
Using the Peel-off Mode without the Present
Sensor installed and enabled can cause labels to
become jammed in the Printer.
Getting Started
11
