5.3.1

Media Width Adjustment

This adjustment allows the use of narrower media, (less than 4 inches
wide) in the Printer.
1. Rotate the Head Level Adjustment Knob clockwise to raise the
minimum printhead to platen position for narrow media.
Note: Rotate the head level adjustment knob counterclockwise to
lower the minimum printhead to position.
2. Install the media, (see Section 2.5).
3. Print a Self-Test Label, (see Section 3.3).
4. If the print quality is unacceptable, repeat steps 1 and 3 until the print
quality is acceptable.
60
Figure 5-2 Media Width Adjustment
