ADVANCED SETUP
MAINTENANCE
TEST PRINT
CURRENT CONFIG
DATABASE CONFIG
TEST RIBBON
TEST PATTERN
FRONT PANEL
LED TEST
KEYPAD TEST
DISPLAY TEST
TEST I/O
MONITOR GP INPUT
TEST GP OUTPUT
SENSOR READINGS
DIGITAL SENSORS
ANALOG SENSORS
SERIAL LOOPBACK
SERIAL PORTA
INSTALLED OPTION
CUTTER
RIBBON SAVER
ADVANCED SETUP
MODULES
PRINT DIRECTORY
PRINT FILE
COPY MODULE
TEST MODULE
FORMAT MODULE
34
• Prints a configuration test label of current selections
• Prints a configuration label of default menu selections
• Test reflects the status of the ribbon type
• Prints label with a test pattern (to check dot elements)
Exercises the front panel indicator LEDs
•
• Checks the operation of the front panel keypad
• Exercises the front panel LED display
• Allows monitoring of the General Purpose Input
• Allows testing of the General Purpose Output
• Displays the status of the digital and analog sensors
• Displays digital sensors with active values below them
HD Head
=
CT = cutter
LP = label present
RS = ribbon saver
• Displays 4 analog sensors with sensor values below each
THR = Thermal
RIB = Ribbon motion
• Serial loopback connector must be installed for test
• Initiates test (see Self-Test, Section 3.3.)
• Lists options
* = installed
• The optional modules are available
Module Slot A
• Prints contents of selected memory modules
• Prints label, font, or image from selected module
• Copies data from one module to another
• Tests Read/Write operation of selected modules
• Formats the selected memory modules
D=Down
D=Down
Y=Blocked
D=Down
RF* = reflective TOF mode
TR* = Transmissive
(* only the active mode is displayed)
External Flash
Prodigy Max Operator's Manual
U=Up
U=Up
N= Not Blocked
U=Up
