3.1.1

Optional LCD/Keypad Front Panel

The Printer can be equipped with an optional, factory-installed
LCD/Keypad front panel. If this option is installed on your Printer, refer
to this section for menu and function information.
The front panel is equipped with a 2 row x 16 character LCD display and
a (six) 6 key operator's keypad. The three (3) control switches and
indicators operate the same as indicated in Section 3.1.
Figure 3-2 Optional LCD/Keypad Front Panel
Note: If the Printer was purchased with the optional LCD/Keypad
front panel, the configuration for the Printer will be set via the
keypad. On the standard Printer, these configurations are set
through the rear dip switches.
