2.3 Configuration and Test Labels

The Printer is capable of printing both a Configuration Label and a
Test Label. The Configuration Label is used to quickly determine
the configuration setup of the Printer while the Test Label is used as
an aid in Printhead adjustments and determining bad Printheads.

2.3.1 Configuration Label

Below is an illustration of an actual Configuration Label. The label
contains information about the Printer's current setup settings, as
well as the date/time, RAM and ROM checksums, and other
Important information. To print a Configuration and Test Label
follow the outlined steps:
1. Hold in the Feed Button and turn on the Printer until the Printer
feeds one label.
2. After the Printer feeds one label release the Feed Button, after a
brief hesitation the Configuration and Test Label will print.
THU MARCH
VER BA - 03.02
SYSTEM ROM CHECKSUM
FONT
TOTAL
SYSTEM RAM CHECKS GOOD
SERIAL PORT BAUD RATE IS 9600
TRANSFER SWITCH IS ON
SETUP SWITCH 1
ANALOG INPUT VALUES:
PAPER: 236
POT ADJ: 139 BAT VOL: 204
INCH COUNTER
TOTAL LABEL LENGTH IN INCHES
Prodigy Plus
17, 1997
04/08/97
ROM CHECKSUM
ROM CHECKSUM
2
OFF OFF OFF OFF OFF OFF OFF OFF
EDGE: 184
DATE SET
Figure 2-4 Configuration Label
Printer Setup
12:25 077
8F7B IS GOOD
2E7A IS GOOD
BDF5 IS GOOD
3 4 5
TEMP 064
4/07/97
000000170
6 7 8
