Using The Peel And Present Option - Datamax Prodigy Plus Operator's Manual

2.5.2

Using the Peel and Present Option

The Peel and Present Option allows for on-demand label dispensing and
requires the Internal Rewind Option. To use this option follow the
instructions outlined below.
1. Turn off the Printer and open the Side Access Cover.
2. Follow steps 2, 3, and 4 of Section 2.5 before installing media.
3. Open the Lower Front Panel.
4. Using a phillips screw driver, remove the Tear Bar, invert it (flip it
over), and re-install it as shown in Figure 2-8.
Figure 2-8 Using the Peel and Present Option
Note:
If media narrower than 4 inches is used, refer to Section 5.3.1
before loading media.
Prodigy Max Operator's Manual 21
