Appendix E
Cable Listings
Part
Number
556000
556001
556002
899516
Prodigy Plus
Printer to CRT Terminal (DB25P)
RS-232
Printer to PC 9 Pin (DB9S) RS-232
Printer to PC 25 Pin (DB25S) RS-232
Printer to PC Parallel Port (DB25P)
Table E-1 Printer Interface Cables
Pin
1
2
3
4
5
7
14
20
Table E-2 Printer Pin Connections
Description
Description
CHASSIS
TXD (RS-232)
RXD (RS-232)
RTS (4.7k ohm to +5VDC)
CTS (input)
LOGIC GROUND
+5 VDC (100 mA
maximum)
BUSY (output)
E-1
