Appendix B

Switch Settings and Cable Interfacing

Baud 9600
SW-1 off
SW-2 off
SW-3 off
SW-4
on
off
Prodigy Plus
4800 2400
off off
off on
on off
Table B-1 Baud Rate
Data Bits
7
8
Table B-2 Word Length
SW-5 Prodigy Compatible
On Prodigy
Off Prodigy Plus
SW-6 Present Sensor
On Enabled
Off Disabled
SW-7 Ribbon Sensor
On Color (translucent)
Off Black (opaque)
SW-8 Cutter
On Cutter Enabled
Off Cutter Disabled
Table B-3 Options
1200 600
off on
on off
on off
Parity
None
None
300 9600
Test
on on
off on
on on
Stop Bits
2
1
B-1
