is again below the threshold level or the max recording time has elapsed (see Section
4.1.2).
Messages sent to an E-Mail address may additionally include a graphical presentation of the
waveform data (PNG graphics). The waveform data and the FFT are NOT calculated if the
duration of the event exceeds 60 seconds (@ 1000 sps sampling rate).

Alarm messages based on the Alarm threshold are independent from event recording. They
are sent immediately after the alarm threshold is exceeded. In that case, the alarm threshold
can be also set below the alarm threshold.
Additionally you may send other information to any of the contacts, as for example a Daily
Message (see Section 4.4.5), as you can see in the following section "Messages".
If the Network option is active, there are additional messages for common Alarm and common
trigger (see Section 4.6).
After having changed something on the contact list, don't forget to click on the Apply button.
In Fig. 4.4.13 the main page related to contacts is displayed. In each line, the selected messages
for the related contact are highlighted.
Messages
In this section the user can configure each type of notification by inserting the desired information.
In details, it is possible to set the following messages:
Trigger event
•
Alarm 1
•
Alarm 2
•
MR3000CMR3000C_TR_v2.0_rev1.odt
Figure 4.4.13. Summary of contact definition.
