It is highly recommended to test your settings with the Test FTP server button. Your MR needs
Internet access to perform the test.
The FTP send service has two options – both can be active:

In Push mode the MR will push a new event file to the FTP server as soon as recording of
the file is done. The current background file may be updated continuously on the FTP
server. In User paramters > Advanced settings – see chapter 4.4.8 you specify how often
the current background file is updated on the FTP server.
Preserve SD Card hierarchy means that you have the same directory structure on the FTP
server as in the MR ../events/2015/01/09/ - year,month,day and /background/2014/01 –year
month. If this option is not checked, the files are copied to the directories /events and
/background.

In Backup mode the MR will keep the FTP server synchronized with its data. At each
connection, the MR will compare its own data to the FTP data, and any missing file on the
FTP will be copied. This option can be combined with the Push mode. It checks the integrity
of the data on the FTP server in scheduled time intervals.
Backup mode always maintains the hierarchy on the SD Card. If you have not checked this
option above and both, Push mode and Backup mode are enabled, you will have two
copies of the same file on your FTP server – of course this also doubles the amount of data
sent to the FTP server.
NOTE: The name of the main directory for a specific MR (main-dir/events/2014/...) is what
you have set-up as Sub directory Name of the MR. If you change this setting, the
MR will generate a new directory on the FTP server.
4.3.10

SCS Cloud

The MR3000 can be connected to the SCS (Syscom Cloud Software) to easily visualize the data
coming from it. The web address of the cloud software is http://scs.bartec-syscom.com. The MR
must have internet connection to communicate with the SCS. Please see the related tutorial video
"LINK A MR3000 TO THE SCS" on the dedicated
peering MR3000-SCS.
In case of connection MR3000-SCS, the data are stored in a Swiss server.
NOTE: The Cloud option and the FTP send option (Section 4.3.9) can be activated in parallel.
NOTE: When using the SCS, please set the MR time to NTP (refer to Section 4.3.2).
In the Service subsection, it is possible to see if the connection to the SCS is enabled or not.
In the Peering subsection, a code generated from the SCS cloud must be inserted. This allows
connecting the MR3000 to the SCS cloud software. The command "Unpeering" allows eliminating
the connection.
In the Synchronization subsection, the user can
