In case one of the predefined norms (DIN 4150-3, SN 640312, Circulaire du 23/07/1986) has been
selected, then in the field "Setting" after having clicked on "Edit" a windows appears on the screen.
On it, the desired limit curve can be chosen, among those defined by the norm. An example is
shown in Figure 4.4.5 for the DIN 4150-3, where the curves are divided according to denomination
defined in the norm. The button "Restore" allows to come back to the default configuration of the
concerned norm.
If the German or the French regulation is selected, the control of the limit values is done on each of
the three axes. The alarm is activated if at least one of the three axes exceeds the limit values.
MR3000CMR3000C_TR_v2.0_rev1.odt
Figure 4.4.4. Limit values for the German DIN 4150-3, vibration at foundation.
Figure 4.4.5. Choice of the limit curve, for DIN 4150-3 (Germany).
subject to technical change without notice
Vibration
At foundation
At other floor
Long term
Building
Industrial
Residential
Historical
57
