Syscom Video MR3000C User Manual page 21

Tap on the Settings icon and in the
settings screen on the Wi-Fi field.
Make sure Wi-Fi is enabled.
Once you have established the Wi-Fi connection you start the Web browser to talk to the MR3000.
Enter the IP address of the MR (always 192.168.30.1 for the Wi-Fi connection) in the Web-
Browser. You will then be prompted for the user name (user) and the password (serial number of
your MR, e.g. 13050130). After a successful authentication, the main page of the Start screen is
shown.
MR3000CMR3000C_TR_v2.0_rev1.odt
Disconnect any existing Wi-Fi
connection and tap on the SSID of
the MR3000
Figure 3.1.2 Wi-fi settings for Smartphone.
subject to technical change without notice
Enter the pass-phrase (enable
'show password') and tap on the
connect field
First you have to enter user
name and password.. if your
credentials are ok...
21
