The DHCP feature of the router makes sure your PC has acquired an IP address in the same
subnet and communication between MR3000 and PC is possible. Now, you can simply enter the IP
address displayed on the LCD of the MR3000 in your Web browser.
We recommend you to purchase and install a router in your workshop for the exclusive work with
your MR3000.
Generally your workshop router should have the following features:

4 or more LAN ports

1 WAN port to have Internet access (optional, but recommended e.g. for firmware upgrades)

DHCP (DHCP = Dynamic Host Configuration Protocol – i.e. the router assigns the IP
addresses) feature

Wi-Fi access point (optional, but convenient, as you don't need a wired connection to your PC)

PoE capabilities (optional – if the router has PoE, the MR3000 is powered over the LAN
connection and you don't have to hook-up an additional cable for supply power).
3.1.3

Wired connection without router

If you connect the MR directly to your computer, you must then configure the IP address of your
computer. The default IP address of the MR is 192.168.1.2, and is displayed on the LCD. Therefore
you must assign a static IP address to your computer, on the same sub-network as the MR. For
example, 192.168.1.3.
Zeroconfig address assignment using APIPA (Automatic Private IP Address Assignment) is not
supported.
3.2

Connecting to the MR3000 in the field (remote connection)

For a remote connection (for example from your office to the MR at site) you need Internet access
and you have to use of the following possibilities:
connect to the SCS (Syscom Cloud software)
•
enable the OpenVPN or DDNS service.
•
For the Internet access you have to use the packet data service of a GSM or UMTS network
(GPRS/EDGE or HSPA) to access the Internet. (see chapter 4.3.5).
SCS cloud software
The SCS (Syscom Cloud Software) allows to change the most important parameters of the MR
without requiring any additional services like OpenVPN or DDNS. The procedure is the following:
1. Log in the SCS at
2. Create a project
3. Link the MR3000 in one project
4. Click on the recorder name to access its setting
MR3000CMR3000C_TR_v2.0_rev1.odt
scs.bartec-syscom.com
