Express-TL User's Guide
4.4.8

Power and Ground

Name Pin #
VCC_12V C104, C105, C106, C107, C108,
C109, D104, D105, D106,
D107, D108, D109
GND C1, C2, C5, C8, C11, C14, C21,
C31, C41, C51, C60, C70, C73,
C76, C80, C84, C87, C90, C93,
C96, C100, C103, C110, D1, D2,
D5, D8, D11, D14, D21, D31,
D41, D51, D60, D67, D70, D73,
D76, D80, D84, D87, D90, D93,
D96, D100, D103, D110
Page 57
Description
Primary power input supports wide range 5~ 20V
input. All available VCC_12V pins on the connector(s)
shall be used.
Ground - DC power and signal and AC signal return
path.
Copyright © 2022 ADLINK Technology, Inc.
I/O PU / PD Comment
P 8.5-20 V
P
PICMG COM.0 R3.0
