Express-TL User's Guide

5.5. Fan Connector

Connector type: JVE 24W1125A-04M00
Page 63
Name
Description
1
FAN_PWMOUT
2
FAN_TACHIN
3
GND
4
12V
Copyright © 2022 ADLINK Technology, Inc.
4 3 2 1
PICMG COM.0 R3.0
