Express-TL User's Guide
4.3.7

LPC Bus

Name Pin # Description
LPC_AD0 B4 LPC multiplexed address, command and data bus
LPC_AD1 B5
LPC_AD2 B6
LPC_AD3 B7
LPC_FRAME# B3 LPC frame indicates the start of an LPC cycle
LPC_DRQ0# B8 LPC serial DMA request
B9
LPC_DRQ1#
LPC_SERIRQ A50 LPC serial interrupt
LPC_CLK B10 LPC clock output –33MHz nominal
Note: LPC Bus is supported by an eSPI to LPC bridge IC
Page 34
I/O
I/O 3.3VSB
O 3.3VSB
I 3.3V
I/O 3.3VSB
O 3.3VSB
Copyright © 2022 ADLINK Technology, Inc.
PU / PD Comment
Not connected
PU 8.2K
3.3VSB
The LPC_CLK frequency is 24MHz on this platform
PICMG COM.0 R3.0
