Express-TL User's Guide
Name Pin # Description
PEG_TX11+ D88 PCI Express Graphics transmit differential pairs.
PEG_TX11- D89 These are the same lines as PCIE_TX[16:31]+ and – in Module pin-
out Type 6
PEG_RX11+ C88 PCI Express Graphics receive differential pairs.
PEG_RX11- C89 These are the same lines as PCIE_TX[16:31]+ and – in Module pin-
out Type 6
PEG_TX12+ D91 PCI Express Graphics transmit differential pairs.
PEG_TX12- D92 These are the same lines as PCIE_TX[16:31]+ and – in Module pin-
out Type 6
PEG_RX12+ C91 PCI Express Graphics receive differential pairs.
C92 These are the same lines as PCIE_TX[16:31]+ and – in Module pin-
PEG_RX12-
out Type 6
PEG_TX13+ D94 PCI Express Graphics transmit differential pairs.
PEG_TX13- D95 These are the same lines as PCIE_TX[16:31]+ and – in Module pin-
out Type 6
PEG_RX13+ C94 PCI Express Graphics receive differential pairs.
PEG_RX13- C95 These are the same lines as PCIE_TX[16:31]+ and – in Module pin-
out Type 6
PEG_TX14+ D98 PCI Express Graphics transmit differential pairs.
PEG_TX14- D99 These are the same lines as PCIE_TX[16:31]+ and – in Module pin-
out Type 6
PEG_RX14+ C98 PCI Express Graphics receive differential pairs.
PEG_RX14- C99 These are the same lines as PCIE_TX[16:31]+ and – in Module pin-
out Type 6
PEG_TX15+ D101 PCI Express Graphics transmit differential pairs.
PEG_TX15- D102 These are the same lines as PCIE_TX[16:31]+ and – in Module pin-
out Type 6
PEG_RX15+ C101 PCI Express Graphics receive differential pairs.
PEG_RX15- C102 These are the same lines as PCIE_TX[16:31]+ and – in Module pin-
out Type 6
PEG_LANE_RV# D54 PCI Express Graphics lane reversal input strap. Pull low on the
Carrier Board to reverse lane order.
Page 55 Copyright © 2022 ADLINK Technology, Inc.
I/O PU / PD Comment
O PCIE AC coupled on Module
I PCIE AC coupled off Module
O PCIE AC coupled on Module
I PCIE AC coupled off Module
O PCIE AC coupled on Module
I PCIE AC coupled off Module
O PCIE AC coupled on Module
I PCIE AC coupled off Module
O PCIE AC coupled on Module
I PCIE AC coupled off Module
I 3.3V
PICMG COM.0 R3.0
