Express-TL User's Guide

4.3.10 Miscellaneous

Name Pin # Description
SPKR B32 Output for audio enunciator, the "speaker" in PC-AT
systems
WDT B27 Output indicating that a watchdog time-out event has
occurred.
THRM# B35 Input from off-module temp sensor indicating an over-
temp situation.
THRMTRIP# A35 Active low output indicating that the CPU has entered
thermal shutdown.
FAN_PWMOUT B101 Fan speed control. Uses the Pulse Width Modulation
(PWM) technique to control the fan's RPM.
FAN_TACHIN B102 Fan tachometer input for a fan with a two-pulse output.
TPM_PP A96 Trusted Platform Module (TPM) Physical Presence pin.
Active high. TPM chip has an internal pull down. This
signal is used to indicate Physical Presence to the TPM.
Page 37
I/O
O 3.3V
O 3.3V
I 3.3VSB
O 3.3VSB
O OD 3.3V
I OD 3.3V
I 3.3V
Copyright © 2022 ADLINK Technology, Inc.
PU / PD Comment
PU 10K 3.3V
PU 100K
3.3VSB
There shall be PD on carrier board
PU 47K 3.3V
PD 100K PD only when TPM on module.
Modules implementing a TPM shall pull down
PICMG COM.0 R3.0
