ADLINK Technology intel COM Express Express-TL User Manual page 28

Express-TL User's Guide
4.3.3.1. Single/Dual Channel LVDS (default)
Name Pin # Description
LVDS_A0+ A71 LVDS Channel A differential pairs
LVDS_A0- A72
LVDS_A1+ A73
LVDS_A1- A74
LVDS_A2+ A75
LVDS_A2- A76
LVDS_A3+ A78
LVDS_A3- A79
LVDS_A_CK+ A81 LVDS Channel A differential clock
LVDS_A_CK- A82
LVDS_B0+ B71 LVDS Channel B differential pairs
LVDS_B0- B72
LVDS_B1+ B73
LVDS_B1- B74
LVDS_B2+ B75
LVDS_B2- B76
LVDS_B3+ B77
LVDS_B3- B78
LVDS_B_CK+ B81 LVDS Channel B differential clock
LVDS_B_CK- B82
LVDS_VDD_EN A77 LVDS panel power enable
LVDS_BKLT_EN B79 LVDS panel backlight enable
LVDS_BKLT_CTRL B83 LVDS panel backlight brightness control
LVDS_I2C_CK A83 DDC lines used for flat panel detection and control.
LVDS_I2C_DAT A84 DDC lines used for flat panel detection and control.
Page 28
I/O
O LVDS
O LVDS
O LVDS
O LVDS
O 3.3V
O 3.3V
O 3.3V
O 3.3V
I/O 3.3V
Copyright © 2022 ADLINK Technology, Inc.
PU / PD Comment
PD 100K
PD 100K
PD 100K
PU 2k2 3.3V
PU 2k2 3.3V
PICMG COM.0 R3.0
