4.3.5

SATA

Name Pin # Description
SATA0_TX+ A16 Serial ATA channel 0, Transmit Output differential pair.
SATA0_TX- A17
SATA0_RX+ A19 Serial ATA channel 0, Receive Input differential pair.
SATA0_RX- A20
SATA1_TX+ B16 Serial ATA channel 1, Transmit Output differential pair.
SATA1_TX- B17
SATA1_RX+ B19 Serial ATA channel 1, Receive Input differential pair.
SATA1_RX- B20
SATA2_TX+ A22 Serial ATA channel 2, Transmit Output differential pair.
SATA2_TX- A23
SATA2_RX+ A25 Serial ATA channel 2, Receive Input differential pair.
SATA2_RX- A26
SATA3_TX+ B22 Serial ATA channel 3, Transmit Output differential pair.
SATA3_TX- B23
SATA3_RX+ B25 Serial ATA channel 3, Receive Input differential pair.
SATA3_RX- B26
(S)ATA_ACT# A28 ATA (parallel and serial) or SAS activity indicator, active low.
4.3.5.1. PCH HSIO Lane Assignments
Name HSIO name on SOC
SATA0 HSIO 26
SATA1 HSIO 27
SATA2 HSIO 28
SATA3 HSIO 29
Page 31
Comment
Copyright © 2022 ADLINK Technology, Inc.
I/O PU / PD Comment
AC coupled on Module
O SATA
AC coupled on Module
I SATA
AC coupled on Module
O SATA
AC coupled on Module
I SATA
AC coupled on Module
O SATA
AC coupled on Module
I SATA
AC coupled on Module
O SATA
AC coupled on Module
I SATA
AC coupled on Module
O 3.3V PU 10K
3.3V
PICMG COM.0 R3.0
