Express-TL User's Guide
Row A
A71 LVDS_A0+ / eDP_TX2+
A72 LVDS_A0- / eDP_TX2-
A73 LVDS_A1+ / eDP_TX1+
A74 LVDS_A1- / eDP_TX1-
A75 LVDS_A2+ / eDP_TX0+
A76 LVDS_A2- / eDP_TX0-
A77 LVDS_VDD_EN / eDP_VDD_EN
A78 LVDS_A3+
A79 LVDS_A3-
A80 GND (FIXED)
A81 LVDS_A_CK+ / eDP_TX3+
A82 LVDS_A_CK- / eDP_TX3-
A83 LVDS_I2C_CK / eDP_AUX+
A84 LVDS_I2C_DAT / eDP_AUX-
A85 GPI3
A86 RSVD
A87 eDP_HPD
A88 PCIE0_CK_REF+
A89 PCIE0_CK_REF-
A90 GND (FIXED)
A91 SPI_POWER
A92 SPI_MISO
A93 GPO0
A94 SPI_CLK
A95 SPI_MOSI
A96 TPM_PP
A97 TYPE10#
A98 SER0_TX
A99 SER0_RX
A100 GND (FIXED)
A101 SER1_TX/CAN_TX
A102 SER1_RX/CAN_RX
A103 LID#
A104 VCC_12V
A105 VCC_12V
Page 22
Row B
B71 LVDS_B0+
B72 LVDS_B0-
B73 LVDS_B1+
B74 LVDS_B1-
B75 LVDS_B2+
B76 LVDS_B2-
B77 LVDS_B3+
B78 LVDS_B3-
B79 LVDS_BKLT_EN
B80 GND (FIXED)
B81 LVDS_B_CK+
B82 LVDS_B_CK-
B83 LVDS_BKLT_CTRL / eDP_BKLT_CTRL
B84 VCC_5V_SBY
B85 VCC_5V_SBY
B86 VCC_5V_SBY
B87 VCC_5V_SBY
B88 BIOS_DIS1#
B89 VGA_RED *
B90 GND (FIXED)
B91 VGA_GRN *
B92 VGA_BLU *
B93 VGA_HSYNC *
B94 VGA_VSYNC *
B95 VGA_I2C_CK *
B96 VGA_I2C_DAT *
B97 SPI_CS#
B98 RSVD
B99 RSVD
B100 GND (FIXED)
B101 FAN_PWMOUT
B102 FAN_TACHIN
B103 SLEEP#
B104 VCC_12V
B105 VCC_12V
Copyright © 2022 ADLINK Technology, Inc.
Row C
C71 PEG_RX6+
C72 PEG_RX6-
C73 GND
C74 PEG_RX7+
C75 PEG_RX7-
C76 GND
C77 RSVD
C78 PEG_RX8+
C79 PEG_RX8-
C80 GND (FIXED)
C81 PEG_RX9+
C82 PEG_RX9-
C83 RSVD
C84 GND
C85 PEG_RX10+
C86 PEG_RX10-
C87 GND
C88 PEG_RX11+
C89 PEG_RX11-
C90 GND (FIXED)
C91 PEG_RX12+
C92 PEG_RX12-
C93 GND
C94 PEG_RX13+
C95 PEG_RX13-
C96 GND
C97 RSVD
C98 PEG_RX14+
C99 PEG_RX14-
C100 GND (FIXED)
C101 PEG_RX15+
C102 PEG_RX15-
C103 GND
C104 VCC_12V
C105 VCC_12V
PICMG COM.0 R3.0
Row D
D71 PEG_TX6+
D72 PEG_TX6-
D73 GND
D74 PEG_TX7+
D75 PEG_TX7-
D76 GND
D77 RSVD
D78 PEG_TX8+
D79 PEG_TX8-
D80 GND (FIXED)
D81 PEG_TX9+
D82 PEG_TX9-
D83 RSVD
D84 GND
D85 PEG_TX10+
D86 PEG_TX10-
D87 GND
D88 PEG_TX11+
D89 PEG_TX11-
D90 GND (FIXED)
D91 PEG_TX12+
D92 PEG_TX12-
D93 GND
D94 PEG_TX13+
D95 PEG_TX13-
D96 GND
D97 RSVD
D98 PEG_TX14+
D99 PEG_TX14-
D100 GND (FIXED)
D101 PEG_TX15+
D102 PEG_TX15-
D103 GND
D104 VCC_12V
D105 VCC_12V
