ADLINK Technology intel COM Express Express-TL User Manual page 54

Express-TL User's Guide
Name Pin # Description
PEG_RX5+ C68 PCI Express Graphics receive differential pairs.
PEG_RX5- C69 These are the same lines as PCIE_TX[16:31]+ and – in Module pin-
out Type 6
PEG_TX6+ D71 PCI Express Graphics transmit differential pairs.
PEG_TX6- D72 These are the same lines as PCIE_TX[16:31]+ and – in Module pin-
out Type 6
PEG_RX6+ C71 PCI Express Graphics receive differential pairs.
PEG_RX6- C72 These are the same lines as PCIE_TX[16:31]+ and – in Module pin-
out Type 6
PEG_TX7+ D74 PCI Express Graphics transmit differential pairs.
PEG_TX7- D75 These are the same lines as PCIE_TX[16:31]+ and – in Module pin-
out Type 6
PEG_RX7+ C74 PCI Express Graphics receive differential pairs.
PEG_RX7- C75 These are the same lines as PCIE_TX[16:31]+ and – in Module pin-
out Type 6
PEG_TX8+ D78 PCI Express Graphics transmit differential pairs.
PEG_TX8- D79 These are the same lines as PCIE_TX[16:31]+ and – in Module pin-
out Type 6
PEG_RX8+ C78 PCI Express Graphics receive differential pairs.
PEG_RX8- C79 These are the same lines as PCIE_TX[16:31]+ and – in Module pin-
out Type 6
PEG_TX9+ D81 PCI Express Graphics transmit differential pairs.
PEG_TX9- D82 These are the same lines as PCIE_TX[16:31]+ and – in Module pin-
out Type 6
PEG_RX9+ C81 PCI Express Graphics receive differential pairs.
PEG_RX9- C82 These are the same lines as PCIE_TX[16:31]+ and – in Module pin-
out Type 6
PEG_TX10+ D85 PCI Express Graphics transmit differential pairs.
PEG_TX10- D86 These are the same lines as PCIE_TX[16:31]+ and – in Module pin-
out Type 6
PEG_RX10+ C85 PCI Express Graphics receive differential pairs.
PEG_RX10- C86 These are the same lines as PCIE_TX[16:31]+ and – in Module pin-
out Type 6
Page 54 Copyright © 2022 ADLINK Technology, Inc.
I/O PU / PD Comment
I PCIE AC coupled off Module
O PCIE AC coupled on Module
I PCIE AC coupled off Module
O PCIE AC coupled on Module
I PCIE AC coupled off Module
O PCIE AC coupled on Module
I PCIE AC coupled off Module
O PCIE AC coupled on Module
I PCIE AC coupled off Module
O PCIE AC coupled on Module
I PCIE AC coupled off Module
PICMG COM.0 R3.0
