Express-TL User's Guide
4.4.6

PCIe Graphics Port (PEG)

Name Pin # Description
PEG_TX0+ D52 PCI Express Graphics transmit differential pairs.
PEG_TX0- D53 These are the same lines as PCIE_TX[16:31]+ and – in Module pin-
out Type 6
PEG_RX0+ C52 PCI Express Graphics receive differential pairs.
PEG_RX0- C53 These are the same lines as PCIE_TX[16:31]+ and – in Module pin-
out Type 6
PEG_TX1+ D55 PCI Express Graphics transmit differential pairs.
PEG_TX1- D56 These are the same lines as PCIE_TX[16:31]+ and – in Module pin-
out Type 6
PEG_RX1+ C55 PCI Express Graphics receive differential pairs.
PEG_RX1-
C56 These are the same lines as PCIE_TX[16:31]+ and – in Module pin-
out Type 6
PEG_TX2+ D58 PCI Express Graphics transmit differential pairs.
PEG_TX2- D59 These are the same lines as PCIE_TX[16:31]+ and – in Module pin-
out Type 6
PEG_RX2+ C58 PCI Express Graphics receive differential pairs.
PEG_RX2- C59 These are the same lines as PCIE_TX[16:31]+ and – in Module pin-
out Type 6
PEG_TX3+ D61 PCI Express Graphics transmit differential pairs.
PEG_TX3- D62 These are the same lines as PCIE_TX[16:31]+ and – in Module pin-
out Type 6
PEG_RX3+ C61 PCI Express Graphics receive differential pairs.
PEG_RX3- C62 These are the same lines as PCIE_TX[16:31]+ and – in Module pin-
out Type 6
PEG_TX4+ D65 PCI Express Graphics transmit differential pairs.
PEG_TX4- D66 These are the same lines as PCIE_TX[16:31]+ and – in Module pin-
out Type 6
PEG_RX4+ C65 PCI Express Graphics receive differential pairs.
PEG_RX4- C66 These are the same lines as PCIE_TX[16:31]+ and – in Module pin-
out Type 6
PEG_TX5+ D68 PCI Express Graphics transmit differential pairs.
PEG_TX5- D69 These are the same lines as PCIE_TX[16:31]+ and – in Module pin-
out Type 6
Page 53 Copyright © 2022 ADLINK Technology, Inc.
I/O PU / PD Comment
O PCIE AC coupled on Module
I PCIE AC coupled off Module
O PCIE AC coupled on Module
I PCIE AC coupled off Module
O PCIE AC coupled on Module
I PCIE AC coupled off Module
O PCIE AC coupled on Module
I PCIE AC coupled off Module
O PCIE AC coupled on Module
I PCIE AC coupled off Module
O PCIE AC coupled on Module
PICMG COM.0 R3.0
