ADLINK Technology intel COM Express Express-TL User Manual page 21

Express-TL User's Guide
Row A
A36 USB6-
A37 USB6+
A38 USB_6_7_OC#
A39 USB4-
A40 USB4+
A41 GND (FIXED)
A42 USB2-
A43 USB2+
A44 USB_2_3_OC#
A45 USB0-
A46 USB0+
A47 VCC_RTC
A48 RSVD
A49 GBE0_SDP
A50 LPC_SERIRQ/ESPI_CS1#
A51 GND (FIXED)
A52 PCIE_TX5+
A53 PCIE_TX5-
A54 GPI0
A55 PCIE_TX4+
A56 PCIE_TX4-
A57 GND
A58 PCIE_TX3+
A59 PCIE_TX3-
A60 GND (FIXED)
A61 PCIE_TX2+
A62 PCIE_TX2-
A63 GPI1
A64 PCIE_TX1+
A65 PCIE_TX1-
A66 GND
A67 GPI2
A68 PCIE_TX0+
A69 PCIE_TX0-
A70 GND (FIXED)
Page 21
Row B
B36 USB7-
B37 USB7+
B38 USB_4_5_OC#
B39 USB5-
B40 USB5+
B41 GND (FIXED)
B42 USB3-
B43 USB3+
B44 USB_0_1_OC#
B45 USB1-
B46 USB1+
B47 ESPI_EN#
B48 USB0_HOST_PRSNT
B49 SYS_RESET#
B50 CB_RESET#
B51 GND (FIXED)
B52 PCIE_RX5+
B53 PCIE_RX5-
B54 GPO1
B55 PCIE_RX4+
B56 PCIE_RX4-
B57 GPO2
B58 PCIE_RX3+
B59 PCIE_RX3-
B60 GND (FIXED)
B61 PCIE_RX2+
B62 PCIE_RX2-
B63 GPO3
B64 PCIE_RX1+
B65 PCIE_RX1-
B66 WAKE0#
B67 WAKE1#
B68 PCIE_RX0+
B69 PCIE_RX0-
B70 GND (FIXED)
Copyright © 2022 ADLINK Technology, Inc.
Row C
C36 DDI3_CTRLCLK_AUX+
C37 DDI3_CTRLDATA_AUX-
C38 DDI3_DDC_AUX_SEL
C39 DDI3_PAIR0+
C40 DDI3_PAIR0-
C41 GND (FIXED)
C42 DDI3_PAIR1+
C43 DDI3_PAIR1-
C44 DDI3_HPD
C45 RSVD
C46 DDI3_PAIR2+
C47 DDI3_PAIR2-
C48 RSVD
C49 DDI3_PAIR3+
C50 DDI3_PAIR3-
C51 GND (FIXED)
C52 PEG_RX0+
C53 PEG_RX0-
C54 TYPE0#
C55 PEG_RX1+
C56 PEG_RX1-
C57 TYPE1#
C58 PEG_RX2+
C59 PEG_RX2-
C60 GND (FIXED)
C61 PEG_RX3+
C62 PEG_RX3-
C63 RSVD
C64 RSVD
C65 PEG_RX4+
C66 PEG_RX4-
C67 RAPID_SHUTDOWN
C68 PEG_RX5+
C69 PEG_RX5-
C70 GND (FIXED)
PICMG COM.0 R3.0
Row D
D36 DDI1_PAIR3+
D37 DDI1_PAIR3-
D38 GND
D39 DDI2_PAIR0+
D40 DDI2_PAIR0-
D41 GND (FIXED)
D42 DDI2_PAIR1+
D43 DDI2_PAIR1-
D44 DDI2_HPD
D45 GND
D46 DDI2_PAIR2+
D47 DDI2_PAIR2-
D48 GND
D49 DDI2_PAIR3+
D50 DDI2_PAIR3-
D51 GND (FIXED)
D52 PEG_TX0+
D53 PEG_TX0-
D54 PEG_LANE_RV#
D55 PEG_TX1+
D56 PEG_TX1-
D57 TYPE2#
D58 PEG_TX2+
D59 PEG_TX2-
D60 GND (FIXED)
D61 PEG_TX3+
D62 PEG_TX3-
D63 RSVD
D64 RSVD
D65 PEG_TX4+
D66 PEG_TX4-
D67 GND
D68 PEG_TX5+
D69 PEG_TX5-
D70 GND (FIXED)
