4.3.16 Power and Ground

Name Pin #
VCC_12V A104, A105, A106, A107, A108,
A109, B104, B105, B106, B107,
B109
VCC_5V_SBY B84, B85, B86, B87
VCC_RTC A47
GND A1, A11, A21, A31, A41, A51,
A57, A60, A66, A70, A80, A90,
A100, A110, B1, B11, B21, B31,
B41, B51, B60, B70, B80, B90,
B100, B110
Page 41
Description
Primary power input supports wide range 5~ 20V
input
All available VCC_12V pins on the connector(s) shall be
used.
Standby power input: +5.0V nominal. If VCC5_SBY is
used, all available VCC_5V_SBY pins on the
connector(s) shall be used. Only used for standby and
suspend functions. May be left unconnected if these
functions are not used in the system design.
Real-time clock circuit-power input. Nominally +3.0V.
Ground - DC power and signal and AC signal return
path.
Copyright © 2022 ADLINK Technology, Inc.
I/O PU / PD Comment
P 8.5-20 V
P 5Vsb ±5%
P
P
PICMG COM.0 R3.0
