HARDWARE SPECIFICATION
General properties
Storage temperature
IP Classification
Dimensions [L x W x D]
Weight - Base unit without fingers or cups
Weight - With fingers, pads on one finger, bracket for
cups and cups
Operating Conditions
Power supply
Current consumption
Operation temperature
Relative humidity (non-condensing)
Force vs Current Graph
Force Sensor
The gripper has a force sensor in the moving finger as shown in the figure below.
Minimum Typical Maximum Unit
0
-
32
-
54
400 x 121.6 x 188
15.75 x 4.79 x 7.4
3.7
8.16
5.2
11.46
Minimum
Typical
20
24
-
-
5
-
41
-
0
-
60
[°C]
140
[°F]
[mm]
[inch]
[kg]
[lb]
[kg]
[lb]
Maximum
Unit
25
[V]
2000
[mA]
50
[°C]
122
[°F]
95
[%]
59
