Chapter 3: Jumpers and Switches
DIP Switch Settings
Function Selection Switch
Connector location: SW2
1 2
Input Voltage Control
Pin
Definition
1 OFF, 2 OFF
12V
1 OFF, 2 ON
24V
1 ON, 2 ON
9-36V (Default)
Copyright © 2018 NEXCOM International Co., Ltd. All Rights Reserved.
RTC Clear CMOS
Connector location: SW3
1 2
Pin
Definition
RTC Normal (Default)
1 OFF, 2 OFF
ME Normal (Default)
RTC Clear CMOS
1 ON, 2 ON
ME Clear
13
