Appendix E: Power Consumption

a e: P
PPendIx
OS: Windows 10
Burn-in Software:
Device:
Idle: Into OS (SSD) + Display + All modules don't link and don't transmit.
Full: Into OS (SSD) + Display + 3G link player video + GPS link + mSATA (transmit) + USB device trans + Run BURN-IN (100%)
Full + Load: Full status + USB load (5V/0.5A)
Item Device
Idle State
1 S0 state Full State
Full State + Loading
Full state
2 IGN OFF
IGNITION OFF
Copyright © 2018 NEXCOM International Co., Ltd. All rights reserved
C
ower onsumPtIon
Test Case
12V
24V
36V
12V
24V
36V
12V
24V
36V
12V
24V
Result
Current(A) Watt(W)
0.506 6.072
0.258 6.192
0.202 7.272
0.9 10.8
0.483 11.592
0.326 11.736
1.125 13.5
0.595 14.28
0.418 15.048
7mA
9mA
49
