Chapter 3: Jumpers and Switches

Mini-PCIe Slot

Connector location: CN8
1 2
51 52
Pin Definition
1 NC
3 NC
5 NC
7 PCIE_CLKREQ#
9 GND
11 PCIE_CLKN1
13 PCIE_CLKP1
15 GND
17 NC
19 NC
21 GND
23 PCIE_RXN1 / SATA_RXN1
25 PCIE_RXP1 / SATA_RXP1
* When CTRL=0, CN6 is mSATA.
* When CTRL=1, CN6 is PCIe devices.
Copyright © 2018 NEXCOM International Co., Ltd. All Rights Reserved.
Pin Definition
2 +V3.3_MINI_2
4 GND
6 +V1.5S_MINI_2
8 NC
10 NC
12 NC
14 NC
16 NC
18 GND
20 PCIE_DISABLE#
22 PCIE_RST#
24 +V3.3_MINI_2
26 GND
Pin Definition
27 GND
29 GND
31 PCIE_TXN1 / SATA_TXN1
33 PCIE_TXP1 / SATA_TXP1
35 GND
37 GND
39 +V3.3_MINI_2
41 +V3.3_MINI_2
43 GND
45 NC
47 NC
49 NC
51 CTRL0
25
Pin Definition
28 +V1.5S_MINI_2
30 NC
32 NC
34 GND
36 NC
38 NC
40 GND
42 3.5G_LED#
44 NC
46 NC
48 +V1.5S_MINI_2
50 GND
52 +V3.3_MINI_2
