Chapter 2: Jumpers and Connectors

Connector Pin Definitions

External I/O Interfaces - Front Panel

Power Button

Connector location: SW5
Pin Definition
1 GND
3 H_PWRBTN#_M
A1 PWR_SW_P
MH1 NC
Copyright © 2017 NEXCOM International Co., Ltd. All Rights Reserved.
Pin Definition
2 H_PWRBTN#_M
4 GND
C1 PWR_SW_N
MH2 NC

LED Indicators

Connector location: LED1, LED2 and LED3
LED1 LED2
LAN
TX1
ACT3
RX1
ACT2
TX2 *ACT1
RX2
HDD
Pin Definition
A1 VCC3
A2 VCC3
LED1
A3 NETX100_RUN
A4 VCC3
A1 VCC3
A2 VCC3
LED2
A3 NETX100_RUN
A4 VCC3
A1 VCC3
A2 VCC3
LED3
A3 NETX100_RUN
A4 VCC3
*Note: The LEDs shown above are for NISE 3800E/E2/P2/P2E & NISE 3800R. The
NISE 3800E-H110 model features two LAN ports and two respective LED indicators
on the front panel.
22
LED3
GPO
GPO #1
GPO #2
DIAG #1
DIAG #2
DIAG
Pin Definition
C1 COM2_RXLEDN
C2 COM2_TXLEDN
C3 COM1_RXLEDN
C4 COM1_TXLEDN
C1 SATALED#
C2 LAN3_ACT#_LED
C3 LAN2_ACT#_LED
C4 LAN1_ACT#_LED
C1 DIAG2_C
C2 DIAG1_C
C3 SIO_GP15_66
C4 SIO_GP16_67
