Chapter 1: Product Introduction
C
1: P
haPter
roduCt
NISE 3800E/E2/P2/P2E Overview
NISE 3800E Front View
NISE 3800E2/P2/P2E Front View
Copyright © 2017 NEXCOM International Co., Ltd. All Rights Reserved.
I
ntroduCtIon
NISE 3800E Rear View
NISE 3800E2/P2/P2E Rear View
Key Features
▪ Support 6th generation Intel
embedded processor
▪ Intel
Q170 PCH
®
▪ Support 1 x 2.5" SATA HDD
▪ 1 x DVI-D, 1 x DP, and 1 x HDMI with independent display support
▪ Three Intel
®
GbE LAN ports; support WoL, teaming and PXE
▪ 1 x External M.2 socket and 1 x SIM card socket
▪ 4 x USB 3.0, 2 x USB 2.0, 2 x RS232/422/485 with auto flow control
▪ 2 x Internal mini-PCIe sockets support optional Wi-Fi/3.5G/mSATA/Fieldbus
▪ Support +9V to 30VDC input; ATX power mode
▪ One PCIe x4 expansion (NISE 3800E)
▪ 2 x PCI or PCIe x4 expansions (NISE 3800E2/P2/P2E)
1
Core™ i7/i5/i3 LGA socket type
®
NISE 3800 Series User Manual
