Chapter 2: Jumpers and Connectors

Jumpers and DIP Switch Settings

AT/ATX Power Select

Connector type: 2-pin On/Off DIP switch
Connector location: SW2
1 2
Pin Settings
1 PCH_PWRBT_N
2 NC
3 NC
4 ATB
Copyright © 2017 NEXCOM International Co., Ltd. All Rights Reserved.

PCI Express* Bifurcation

Connector type: 2-pin On/Off DIP switch
Connector location: SW4
1 2
Pin Settings
1 CPU_CFG6
2 CPU_CFG5
3 GND
4 GND
20
