Chapter 4: BIOS Setup
PCH-IO Configuration
This section is used to configure PCH-IO configuration.
Aptio Setup Utility - Copyright (C) 2017 American Megatrends, Inc.
Chipset
PCH-IO Configuration
► SATA And RST Configuration
► Security Configuration
► HD Audio Configuration
State After G3 [S0 State]
USB2.0 Power State in Standby [Power Off]
USB3.0 Power State in Standby [Power On]
LAN3 [Enabled]
LAN2 [Enabled]
LAN1 [Enabled]
MINIPCIE(WIFI1) [Enabled]
MINIPCIE(CN2) [Enabled]
M.2 [Enabled]
Version 2.18.1263. Copyright (C) 2017 American Megatrends, Inc.
State After G3
Configures the power state when power is re-applied after a power failure
(G3 state).
USB2.0 Power State in Standby
Configures the USB 2.0 power state in standby mode.
USB3.0 Power State in Standby
Configures the USB 3.0 power state in standby mode.
Copyright © 2017 NEXCOM International Co., Ltd. All Rights Reserved.
LAN1 to LAN3
Enables or disables LAN1 to LAN3 controllers.
MINIPCIE(WIFI1) and MINIPCIE(CN2)
Enables or disables the PCI Express root port for WIFI1 and CN2.
SATA Device Options Settings
M.2
Enables or disables the M.2 connector.
