Overview of ZS5-2 Controller
FIGURE 29
1 Power Supply Unit (PSU) 1
4 Network Management (NET
MGT) 10/100/1000 BASE-T
Ethernet port
7 Network (NET) 10 GbE ports:
NET 0, NET 1, NET 2, NET 3
10 Cluster interface card (slot 4)
Cluster Interface Card Compatibility - The ZS5-2 controller contains a Version 3 cluster
interface card, which is incompatible with Version 2.
For information about how to connect cables to form a cluster, see
Cables" on page
Cable Management Arm
The following figure identifies the components of the cable management arm (CMA). For
installation instructions, see
60
Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021
ZS5-2 Rear Panel
2 Second PCle option (slot 1)
5 First PCle option (slot 5)
8 SER MGT port
11 First 4x4 SAS HBA (slot 2)
220.
"Installing a ZS5-2 Cable Management Arm" on page
3 Third PCle option (slot 3)
6 Second 4x4 SAS HBA, or fourth
PCle option (slot 6)
9 Two USB 3.0 ports
12 Power Supply Unit (PSU) 0
"Connecting Cluster
164.
