Label Color
USR5
USR5
EXT1
EXT2
[1]
The color of the LED represents the signal quality for wireless links.
red means low
yellow means moderate
green means good or excellent
Ethernet LEDs
The following table describes the Ethernet status indicators.
Label Color
ETH1-5
blinking

3.4.3. Reset

The reset button has two functions:
1. Reboot the system:
Press at least 3 seconds to release a system reboot.
The reboot is indicated with the red blinking STAT LED.
2. Factory reset:
Press at least 10 seconds to release a factory reset.
The start of the factory reset is con rmed by all LEDs lighting up for a second.
NB3000-Line-Hd User Manual 4.2
State Function
on User de ned.
off User de ned.
on User de ned.
off User de ned.
on Extension port 1 is on.
off Extension port 1 is off.
on Extension port 2 is on.
off Extension port 2 is off.
Table 3.3.: NB3000-Line-Hd Status Indicators
State Function
on Link on (10 Mbit/s, 100 Mbit/s or 1000 Mbit/s)
Activity
off no Link
Table 3.4.: Ethernet Status Indicators
