3.2.2. USB 2.0 Host Port

The USB 2.0 host port has the following specification:
Feature
Speed
Current
Table 3.3.: USB 2.0 Host Port Specification

3.2.3. RJ45 Ethernet Connectors

Specification
The Ethernet ports are specified as follows:
Feature
Isolation
Speed
Mode
Crossover
Pin Assignment
Pin Signal
1 Tx+
2 Tx
3 Rx+
4 -
5 -
6 Rx
7 -
8 -
Table 3.5.: Pin Assignments of RJ45 Ethernet Connectors
NB2700 User Manual
Specification
Low, Full & Hi-Speed
max. 500 mA
Specification
1500 Vrms
10/100 Mbps
Half- & Full-Duplex
Automatic MDI/MDI-X
Table 3.4.: Ethernet Port Specification
