3.2. Interfaces

3.2.1. Overview

Label Panel
USB Front
Ethernet 1 Front
Ethernet 2 Front
Mobile Front
WLAN1 Front
WLAN2 Front
Top
Power Top
RS-232 Top
Outputs Top
Inputs Top
Reset Top

3.2.2. USB 2.0 Host Port

The USB 2.0 host port comes with the following specification:
NB1600 User Manual
Function
USB 2.0 host port, can be used as USB device server or for
software/configuration updates.
First Ethernet port, can be used as LAN or WAN interface.
Second Ethernet port, can be used as LAN or WAN inter-
face.
SMA female connector for GSM/UMTS antenna
SMA female connector for first WLAN antenna (main)
SMA female connector for second WLAN antenna (diver-
sity)
Earth protection connector (earthing is optional), connected
to the ground of the power supply V
yellow-green marked cable with at least 6
Avoid corrosion and protect the screws against loosening.
Power supply 12-48 V
DC
supply (redundancy) 12-48 V
Non-isolated serial RS-232 interface (Pins 5 to 7) which can
be used for console administration, serial device server or
other serial based communication applications.
Galvanic isolated digital outputs (Pins 8 to 11)
Galvanic isolated digital inputs (Pins 12 to 15)
Reset button, press at least 3 seconds for reboot and at least
5 second for a factory reset. The start of the factory reset is
confirmed by all LEDs lighting up for a second. The button
can be released then again.
Table 3.2.: NB1600 Interfaces
15
. If used, connect a
GND
2
(Pins 1 and 2). Additional power
(Pins 3 and 4)
DC
copper area.
