Nr. Label
10
11
PWR
12
EXT
13
MOB
4/
WLAN 1
14
GNSS
NB3000-Line-Hd User Manual 4.2
Function
Earth protection connector, connected to the ground of the power
supply V
. If used, connect a yellow-green marked cable with at
GND
2
least 6
copper area. Avoid corrosion and protect the screws
against loosening.
Power supply (galvanically isolated)
Galvanically isolated extension ports M12 connector
TNC female connectors for MIMO Mobile/WLAN antenna
TNC female connector for GPS/GLONASS antenna
Table 3.2.: NB3000-Line-Hd Interfaces
